Dolphinmed Portable Veterinary Anesthesia Machine

Dolphinmed Portable Veterinary Anesthesia Machine

Feature

680F model is a compact, stable and reliability portable veterinary anesthesia machine. It mainly used in veterinary clinic, veterinary hospital for animal 0.5-100kg

Specification

Application: Small animal (0.5-100KG).

Respiration mode : Manual mode, open/closed/semi-open/semi-closed mode

Gas source:O2. quick inlet port

Tidal Volume:0-2000ml

O2 FLUSH: 20L/min--75L /min

Flow meter: 02. 0-4L/min, adjustable easily

Airway pressure gauge:-10cmH20-80cmH20

APL valve: adjustable easily, range:0-60cmH20

Inspiration valve and expiration valve, ISO standard port, diameter 22mm

Soda lime chamber:0.8 Liter, easy to change soda lime within one minute

Bains connector for open breath system, like Bains circuit and Jackson circuit

Anesthesia vaporizer: Enflurane, Isoflurane. Halothane or Sevoflurane.

The CO2 circle absorber has a connector porter and can be connected to a vet anesthesia ventilator.

Standard configuration

Optional configuration
